Heavy Duty Outrigger Crane Pad – 400mm to 600mm Square, Recycled UHMWPE, up to 100,000kg

A heavy-duty square outrigger pad that supports cranes, outriggers, powered access platforms and mobile plant machinery. It spreads the load evenly to reduce ground pressure, improving site safety and supporting safer lifting while protecting the ground beneath. Quick to deploy, easy to clean and store, and a cost-effective way to support outriggers.

Features

• Supports up to 100,000kg (subject to ground conditions).
• Made from a mix of 100% recycled high molecular weight and ultra-high molecular weight polyethylene (UHMWPE) for superior strength.
• Lightweight design with a built-in carry handle, so it is easy to move and position.
• Flexible – moulds to uneven or undulating ground for extra stability.
• Weather, water, chemical and oil resistant; impermeable to water, so it can be used in all weather and harsh commercial environments.
• Does not splinter or absorb water, and is designed to be unbreakable under normal working conditions.
• Long-lasting and easy to clean.
• 1-year warranty.

Sizes

• 400mm L x 400mm W x 40mm H (40 x 40 x 4cm)
• 500mm L x 500mm W x 50mm H (50 x 50 x 5cm)
• 600mm L x 600mm W x 60mm H (60 x 60 x 6cm)
• Weight from 6.1kg to 20.5kg depending on size.
• Sizes are subject to a manufacturing tolerance of +/- 5%.

Good to Know

• Load-bearing capacity depends on ground conditions.
• Extreme slopes and very rough terrain may need extra ground preparation.
• The surface design may vary from the images shown.
