Aluminium Wedge Ramp 10mm to 50mm H x 1000mm W x 500mm L – 800kg Capacity
£1,068.00
Not sure it suits your machine?
Send us your load height and machine weight — we'll confirm the right ramp before you order.
Overview
An aluminium wedge ramp that lets trolleys, cages, flight cases and pallet trucks get over low steps and thresholds of up to 50mm in the warehouse and workplace. With an 800kg capacity, it simply rests in place, ready to use.
Specifications
| Ramp Height Option | 10mm H x 1000mm W x 500mm L |
|---|---|
| Height (mm) | 10 - 50 |
| Length (mm) | 500 |
| Width (mm) | 1000 |
| Capacity (kg) | 800 |
| Weight (kg) | 11 - 12 |
| Two Year Warranty | Yes |
| Easy to Fit | Yes |
| European Made | Yes |
| Colour Options | Black |
Features
- Available in heights from 10mm to 50mm.
- Easy to use – just rest it against the step or threshold.
- 1000mm wide x 500mm long, giving a gradient of at least 1:10.
- Smooth gradient for easy loading of items with low ground clearance.
- Chequered anti-slip surface.
- Lightweight and portable, with a built-in carry handle.
- Highly durable 800kg capacity.
- Made from aluminium in Europe, for professional use in warehouses and the workplace.
- Two-year warranty.
Choosing Aluminium
- Aluminium wedge ramps are generally lighter than rubber and can be customised to your requirements.
- Aluminium is especially suited to items with small solid wheels, such as pallet trucks, trolleys with castors and cages.
- Electric pallet trucks are generally suitable when used within the recommended load height and capacity. Many have very low ground clearance, so check your load height and your truck's data sheet to confirm suitability before ordering; custom solutions are available.
Load height checker
Measure straight up from the ground to where the ramps will rest on your vehicle or trailer.
