Extra Heavy Duty Aluminium Industrial Plant Loading Ramps (Pair) – 2500mm L x 550mm W, 20,000kg Capacity
£4,584.00
Not sure it suits your machine?
Send us your load height and machine weight — we'll confirm the right ramp before you order.
Overview
A pair of extra heavy duty aluminium loading ramps, each 2500mm long and 550mm wide with a 230mm profile thickness. With a combined capacity of 20,000kg, they are ideal for industrial plant machinery and heavy duty commercial loading. The price and capacity shown are for the pair. One of the heaviest duty ramps in the standard range.
Specifications
| Size | 2500mm L x 550mm W x 230mm T |
|---|---|
| Height of Ramps Profile (mm) | 230 |
| Length (mm) | 2500 |
| Width (mm) | 550 |
| Minimum Track Width (mm) | 400 |
| Maximum Track Width (mm) | 450 |
| Default Connection | Rest On Connection |
| Capacity (kg) | 20000 |
| Max Load Height (mm) | 750 |
| Min. Load Height (mm) | 600 |
| Weight per Ramp (kg) | 58 |
| Weight Per Pair (kg) | 116 |
| One Year Warranty | Yes |
| Connection Options Available | Yes |
| Customisable | Yes |
| Easy to Fit | Yes |
| European Made | Yes |
| Not Solid Wheels | Yes |
| Capacity Wheelbase 1000mm (kg) | 20,000 |
| Capacity Wheelbase 1500mm (kg) | 20,000 |
| Capacity Wheelbase 2000mm (kg) | 20,000 |
| Min - Max Load Height | 600mm - 750mm |
Features
- Available with or without side edges.
- Four connection options are available; the standard fitting is a rest-on connection.
- Each ramp weighs 58kg (116kg per pair).
Sizing and Loading
- Load height: 600mm to 750mm.
- Track/wheel width: minimum 400mm, maximum 450mm.
- Capacity by machine wheelbase: 20,000kg at 1000mm, 20,000kg at 1500mm, 20,000kg at 2000mm.
Good to Know
- Not suitable for machines with solid wheels, such as road surfacing machines; steel-tracked machinery needs a dedicated industrial ramp.
- Fully TÜV certified. Made in Europe. Easy to fit.
- One-year warranty.
- Custom load heights and custom sizes are available, and quotes for bespoke ramps can be supplied on request.
- Photos are for illustration only; the actual product may vary slightly due to product improvements.
