3-Channel Cable Protector – 1000mm L x 290mm W x 48mm H, 2,000kg, Black/Yellow Non-Slip (Pack of 5)
£1,560.00
incl. VAT · per pack
Not sure which size you need?
Send us your cable or hose diameters and traffic type — we'll confirm the right protector before you order.
Overview
A lightweight 3-channel cable protector with a high-visibility black and yellow finish, made to protect cables from pedestrian traffic indoors and outdoors. It is a popular choice at events, trade shows and exhibitions, and is rated at 2,000kg per 20cm x 20cm and 4,000kg per axle. Suitable for pedestrians, trolleys and goods; not suitable for road traffic.
Specifications
| Size | Pack of 5 – 1000mm L x 290mm W x 48mm H |
|---|---|
| Height (mm) | 48 |
| Length (mm) | 1000 |
| Width (mm) | 290 |
| Channel Size (mm) | 1 channel 35 x 35 mm, 2 channels 35 x 30 mm |
| Capacity (kg) | 2,000kg / 20cm x 20cm |
| Five Years Warranty | Yes |
| Easy to Fit | Yes |
| Leave Outside | Yes |
| Cable Protector Color | Black/Yellow |
| No. Channels | 3 |
| Capacity per Axle (kg) | 4,000 |
| Operating Temperature (deg. F) | -22 to +140 |
| Speedlimit (mph) | 5 |
| Colour Options | Yellow |
Features
- 3 channels: 1 channel 35mm x 35mm and 2 channels 35mm x 30mm, for cables or wires up to 35mm in diameter.
- Chequered, high-visibility non-slip surface and a non-slip base that keeps it in place on a variety of surfaces.
- Interlocking design: connect several units to cover your required cable length.
- Quick to set up: rest it on the floor, open the lid and lay in the cables. The patented self-cleaning lid hinge locks securely when closed.
- Weighs under 6kg, so one person can lift and move it into position.
- Suitable for internal and external use and can be left outside.
Build Quality & Safety
- Made from non-breakable, 100% recyclable polyurethane.
- Resistant to oils, acids, petrol and solvents.
- Temperature resistant from -30°C to +60°C, with a shore A hardness of 88 ± 4.
- Smooth surfaces, edges and corners help prevent injuries.
- Fire protection class E to DIN EN 13501-1 and TÜV SÜD certified.
- Protects low-voltage cables up to 500V, such as communication, control and power-supply cables, as well as water and sewage pipes and hoses. Not suitable for rigid gas pipes.
- Made in Germany. Five-year warranty.
Care & Maintenance
- Easy to clean, even with a steam jet cleaner; little maintenance is needed thanks to the self-cleaning lid.
- Keep the hinge area and lid clean, and lightly lubricate the hinges and closure regularly with a silicone spray. Wipe off any excess afterwards to avoid a slip risk.
Good to Know
- Sold in packs of 5 – the price shown is for a pack of 5 units.
- Also available in all black.
- Accessories are available to fit the run to your area, including 45° left and 45° right curves and female and male end ramps.
- Pictures are for illustration only; the actual product may vary due to product improvements.
