Extra Wide Aluminium Plant Loading Ramps (Pair) – 1500mm to 4000mm L x 500mm W, 65mm Profile

A pair of wide, heavy-duty, non-folding aluminium ramps for commercial use. They bridge the gap between the ground and your vehicle so you can load plant machinery on rubber tracks or rubber wheels onto low-bed trailers, into vans and over steps, including mini diggers, mini excavators, micro dumpers, dumper trucks, ride-on mowers and cars. Popular with construction sites, landscape gardeners, agricultural users, utility contractors and plant hire firms for moving machinery from site to site without damage or injury.

• 500mm wide, with a track width from 300mm to 420mm.
• 65mm low profile.
• Capacity depends on the length chosen; ideal for medium and lightweight plant machinery.
• Weights from 12kg, so they are easy to lift into position.
• Four connection options; the default curved rest-on connection, with a pre-drilled hole plus the supplied pin and plates, suits flat-bed vehicles and tipper trucks. A hook connection is normally recommended for trailers such as beavertail trailers; ask for an alternative connection after ordering.
• Angled foot, cut for the recommended load height, keeps the ramps planted and gives a seamless move from the ground onto the ramp.
• High-traction surface for optimum grip while loading.
• No edges as standard for greater flexibility; edges are available on request.
• Portable: simply rest the ramps on your vehicle, with no vehicle modifications needed, and lay them flat for storage.
• Designed for a maximum loading gradient of 30%, in line with EU guidelines.
• Two-year warranty.

Made in Italy and TÜV certified. Custom options include other lengths and widths, edges, carry handles and custom load heights. For low-clearance items the foot can be cut for a smoother gradient, and a CAD simulation can check that the ramps suit your machine. Bespoke quotes are available on request.

• Not suitable for the solid wheels found on road-surfacing machines; machines on steel tracks need dedicated industrial ramps.
• Stated capacities only apply when the vehicle's weight is evenly distributed.
• To pick a length, measure the vertical height from the ground to where the ramp will rest. Each length has a minimum and maximum load height, based on a maximum 30% gradient in line with EU guidelines.
• For low-clearance cars, dedicated car ramps give a smoother gradient.
• Price and capacity are for the pair.
