900mm Wide Modular Wheelchair Ramp Section – 500mm to 3000mm L, 400kg Capacity
£972.00
Not sure which length you need?
Send us the step height and who will use it — we'll confirm the right ramp before you order.
Overview
A 900mm wide ramp section for a lightweight modular ramp system, available in 500mm, 1000mm, 1250mm, 1500mm, 2000mm, 2500mm and 3000mm lengths. Every section has a 900mm usable width and a maximum load of 400kg, and suits manual wheelchairs, electric wheelchairs and mobility scooters. The price is for the ramp section only – handrails, legs, fixings and other attachments are not included.
Specifications
| Length Options | 500mm L x 900mm W |
|---|---|
| Internal Width (mm) | 900 |
| Length (mm) | 500-3000 |
| Capacity (kg) | 400 |
| Weight (kg) | 6-30 |
| Customisable | Yes |
| Easy to Fit | Yes |
| Electric Wheelchair | Yes |
| European Made | Yes |
| Manual Wheelchair | Yes |
| Mobility Scooter Friendly | Yes |
| Leave Outside | Yes |
Sizes & Weights
- 500mm L (20in) – 6kg (13.2lb)
- 1000mm L (40in) – 12kg (26.4lb)
- 1250mm L (49in) – 15kg (33.1lb)
- 1500mm L (59in) – 18kg (39.7lb)
- 2000mm L (79in) – 24kg (53.0lb)
- 2500mm L (98in) – 30kg (66.1lb)
- 3000mm L (118in) – 36kg (79.4lb)
- All sections: 900mm (35in) usable width, 400kg (880lb) maximum load.
Features
- Easy to fit and suitable to leave outside.
- Made in Europe.
- Customisable – modular ramps can be tailored to your area and needs.
- Modular ramps are usually built to a 1:12 gradient; a gentler gradient can be provided when needed, and the steepest the kits can be built to is 1:10.
- Pictures are for illustration only; the product may vary slightly due to product improvements.
Ramp length checker
Measure from the ground to the top of the step or threshold.
