Extra Wide Mobile Steel Yard Ramp with Hydraulic Assist – 11260mm L x 2460mm W, 10,000kg

A CE-marked, extra-wide mobile steel yard ramp that makes it easier to load wider machinery and speeds up loading and unloading containers. It meets the latest European standards and directives, is rated to 10,000kg and measures 11260mm long with a 2460mm outer width. The fixed swivel clamp lets you move the ramp into position with a forklift, while the hydraulic assist makes it simple to set the load height anywhere from 800mm to 1650mm.

• 10,000kg capacity; outer width 2460mm, usable (internal) width 2260mm; ramp height 800mm.
• Hydraulic assist for easy height adjustment between 800mm and 1650mm.
• Fixed swivel clamp / fork mount so the ramp can be repositioned with a forklift.
• Side profiles made from a single piece of steel for top performance, durability and safety.
• Reinforced steel undercarriage.
• High-traction, UK-produced anti-slip mesh surface.
• Fully certified and tested. European made. Weight 4050kg; can be left outside.
• One-year warranty.

• Swivel fork mount, steel chains and clamps, hydraulic assist and wheel chocks.

• Customisable – handrails can be added on request (quoted separately).
• The gradient is roughly 10%, suitable for most forklifts; it varies with the height of the lorry.
• Inspect the ramp regularly. An annual service is recommended to keep it safe and to comply with PUWER regulations.
• Pictures are for illustration only; the actual product may vary slightly due to product improvements.
